ZU4704PE

Description

• The ZUTP-Series of pumps achieve high pressure without the need for an intensifier. This allows for low maintenance, resulting in less cost for the end-user.
• The ZUTP1500-S Series with pendant-operated solenoid valve is ideal for multiple bolt tensioning applications as it allows for single-person operation. The operator can pressurize and depressurize the tensioner directly from the pendant.
• 1,25 kW heavy-duty universal motor provides the best performance-to-weight ratio
• S version of the ZUTP has solenoid-operated valve with 6 m pendant for remote control of valve and one-man operation
• Easily accessible manual override valve to release pressure if power is lost
• Replaceable 10 micron reservoir breather and inline high pressure filter helps maintain oil cleanliness for optimum performance
• Two-stage pump design provides high flow at low pressure for fast system fills and controlled flow at high pressure for accurate operation
• Panel-mounted 153 mm pressure gauge, with polycarbonate cover, is set into the protective metal shroud for improved visibility
• These products operate at ultra-high pressure, use only the specified fittings and hoses designed for these pressures.
