ZU4204JE

ZU4204JE

SKU: ZU4204JE Categories: , , Brand:
Login to purchase
Enquire for this product

Maximum Operating Pressure bar : 700

Series : ZU

Unit Height Shipping Oracle ERP : 22

Unit Length Shipping Oracle ERP : 21

Unit Width Shipping Oracle ERP : 13

Dimension A mm : 424

Dimension B mm : 142

Dimension C mm : 279

Dimension D mm : 152

Weight Kgs : 27

Hydraulic Pump Cylinder Compatability : Single-acting

Hydraulic Pump Maximum Flow Rate Ranges at Rated Pressure L min : 0,98 - 1,95

Hydraulic Pump Maximum Flowat Rated Pressure : 1,0 l/min

Hydraulic Pump Maximum Operating Pressure Ranges Bar : 700

Hydraulic Pump Motor Electrical Specification : 208-240 V, 1 Ph, 50/60 Hz

Hydraulic Pump Motor Hertz : 50/60 Hz

Hydraulic Pump Motor Phases : 1 Ph

Hydraulic Pump Motor Size Kw : 1,25

Hydraulic Pump Motor Voltage : 208-240 V

Hydraulic Pump Output Flow Rate 350 bar In 3 min : 1,2

Hydraulic Pump Output Flow Rate 350 bar L min : 1,2

Hydraulic Pump Output Flow Rate 50 bar In 3 min : 8,8

Hydraulic Pump Output Flow Rate 50 bar L min : 8,8

Hydraulic Pump Output Flow Rate 700 bar In 3 min : 1,0

Hydraulic Pump Output Flow Rate 700 bar L min : 1,0

Hydraulic Pump Output Flow Rate 7 bar In 3 min : 11,5

Hydraulic Pump Output Flow Rate 7 bar L min : 11,5

Hydraulic Pump Control : Pendant

Hydraulic Pump Power Source : Electric

Hydraulic Pump Relief Valve Adjustment Range bar : 140 - 700

Hydraulic Pump Reservoir Capacity cm3 : 4000

Hydraulic Pump Sound Leveld Ba : 85 - 90

Hydraulic Pump Usable Oil Capacity Litres : 4,0

Hydraulic Pump Valve Function : Advance / Retract

Hydraulic Pump Valve Model : VM32

Hydraulic Pump Valve Operation : Manual

Hydraulic Pump Maximum Flow At Rated Pressure Liter : 1

Hydraulic Pump Maximum Flow At Rated Pressure Metric : 1,0 l/min

Hydraulic Pump Valve Type : 3-way, 2-position

PLG: default Price Group List Price : 1
