Maximum Operating Pressure bar : 700
Series : ZE
Dimension A mm : 457
Dimension B mm : 143
Dimension C mm : 279
Dimension D mm : 206
Dimension H mm : 513
Weight Kgs : 51
Hydraulic Pump Cylinder Compatability : Single-acting
Hydraulic Pump Maximum Flow Rate Ranges at Rated Pressure L min : 0,65 - 0,97
Hydraulic Pump Maximum Flowat Rated Pressure : 0,82 l/min
Hydraulic Pump Maximum Operating Pressure Ranges Bar : 700
Hydraulic Pump Motor Electrical Specification : 380-415 V, 3 Ph, 50-60 Hz
Hydraulic Pump Motor Hertz : 50/60 Hz
Hydraulic Pump Motor Phases : 3 Ph
Hydraulic Pump Motor Size Kw : 1,12
Hydraulic Pump Motor Voltage : 380-415 V
Hydraulic Pump Output Flow Rate 350 bar In 3 min : 0,84
Hydraulic Pump Output Flow Rate 350 bar L min : 0,84
Hydraulic Pump Output Flow Rate 50 bar In 3 min : 8,20
Hydraulic Pump Output Flow Rate 50 bar L min : 8,20
Hydraulic Pump Output Flow Rate 700 bar In 3 min : 0,82
Hydraulic Pump Output Flow Rate 700 bar L min : 0,82
Hydraulic Pump Output Flow Rate 7 bar In 3 min : 8,88
Hydraulic Pump Output Flow Rate 7 bar L min : 8,88
Hydraulic Pump Control : Manual
Hydraulic Pump Power Source : Electric
Hydraulic Pump Relief Valve Adjustment Range bar : 70 - 700
Hydraulic Pump Reservoir Capacity cm3 : 8000
Hydraulic Pump Sound Leveld Ba : 75
Hydraulic Pump Usable Oil Capacity Litres : 8,0
Hydraulic Pump Valve Function : Advance / Retract
Hydraulic Pump Valve Model : VM32
Hydraulic Pump Valve Operation : Manual
Hydraulic Pump Maximum Flow At Rated Pressure Liter : 0.82
Hydraulic Pump Maximum Flow At Rated Pressure Metric : 0,82 l/min
Hydraulic Pump Valve Type : 3-way, 2-position
