ZE4020NW

ZE4020NW

SKU: ZE4020NW Categories: , , Brand:
Login to purchase
Enquire for this product

Maximum Operating Pressure bar : 700

Series : ZE

Unit Height Shipping Oracle ERP : 34

Unit Length Shipping Oracle ERP : 31

Unit Width Shipping Oracle ERP : 25

Dimension A mm : 558

Dimension B mm : 180

Dimension C mm : 419

Dimension D mm : 422

Dimension E mm : 501

Dimension F mm : 488

Dimension H mm : 625

Weight Kgs : 61

Hydraulic Pump Maximum Flow Rate Ranges at Rated Pressure L min : 0,65 - 0,97

Hydraulic Pump Maximum Flowat Rated Pressure : 0,82 l/min

Hydraulic Pump Maximum Operating Pressure Ranges Bar : 700

Hydraulic Pump Motor Electrical Specification : 380-415 V, 3 Ph, 50-60 Hz

Hydraulic Pump Motor Hertz : 50/60 Hz

Hydraulic Pump Motor Phases : 3 Ph

Hydraulic Pump Motor Size Kw : 1,12

Hydraulic Pump Motor Voltage : 380-415 V

Hydraulic Pump Output Flow Rate 350 bar In 3 min : 0,84

Hydraulic Pump Output Flow Rate 350 bar L min : 0,84

Hydraulic Pump Output Flow Rate 50 bar In 3 min : 8,20

Hydraulic Pump Output Flow Rate 50 bar L min : 8,20

Hydraulic Pump Output Flow Rate 700 bar In 3 min : 0,82

Hydraulic Pump Output Flow Rate 700 bar L min : 0,82

Hydraulic Pump Output Flow Rate 7 bar In 3 min : 8,88

Hydraulic Pump Output Flow Rate 7 bar L min : 8,88

Hydraulic Pump Power Source : Electric

Hydraulic Pump Reservoir Capacity cm3 : 20000

Hydraulic Pump Sound Leveld Ba : 75

Hydraulic Pump Usable Oil Capacity Litres : 20,0

Hydraulic Pump Maximum Flow At Rated Pressure Liter : 0.82

Hydraulic Pump Maximum Flow At Rated Pressure Metric : 0,82 l/min

PLG: default Price Group List Price : 1

Description

  • High-efficiency pump design – higher oil flow and by-pass pressure
  • High-strength, moulded electrical box protects electronics, power supplies and LCD readout and stands up to harsh industrial environments
  • IP54 protection and isolation class
  • Back-lit LCD provides self test, diagnostic and read-out capabilities never before offered on an industrial pump (included on pump with electric valves, optional on other models)
  • Totally enclosed, fan-cooled industrial electric motors for extended life
  • User adjustable relief valve built-in on manual and solenoid valves. Oil ports on valves are 3/8″ NPTF
  • Steel fan guard on all electric motors
  • Full sight oil level glass
  • 40 micron filter breather with splash guard
  • Durable steel reservoirs
