ZE2108DE

ZE2108DE

SKU: ZE2108DE Categories: , , Brand:
Login to purchase
Enquire for this product

Maximum Operating Pressure psi : 10,000

Maximum Operating Pressure bar : 700

Series : ZE

Height Dimension mm : 518

Length Dimension mm : 491

Unit weight : 93.5

Weight Kgs : 42,4

Width Dimension mm : 279

Hydraulic Pump Cylinder Compatability : Single-acting

Hydraulic Pump Maximum Operating Pressure Ranges Bar : 700

Hydraulic Pump Maximum Operating Pressure Ranges Psi : 10,000

Hydraulic Pump Motor Hertz : 50/60 Hz

Hydraulic Pump Motor Phases : 1 Ph

Hydraulic Pump Motor Size hp : 0.75

Hydraulic Pump Motor Size Kw : 0,56

Hydraulic Pump Motor Voltage : 208-240 V

Hydraulic Pump Output Flow Rate No Load In 3 min : 200

Hydraulic Pump Output Flow Rate No Load L min : 2,7

Hydraulic Pump Pressure Rating 2nd Stage bar : 700

Hydraulic Pump Pressure Rating 2nd Stage Psi : 10,000

Hydraulic Pump Control : Pendant

Hydraulic Pump Power Source : Electric

Hydraulic Pump Reservoir Capacity Litres : 8

Hydraulic Pump Reservoir Capacity cm3 : 8,000

Hydraulic Pump Reservoir Capacity gal : 2

Hydraulic Pump Soleniod Valve Voltage : 24VDC

Hydraulic Pump Sound Leveld Ba : 79

Hydraulic Pump Usable Oil capacity Gal : 1.8

Hydraulic Pump Usable Oil Capacity Litres : 6,8

Hydraulic Pump Valve Function : Advance / Retract

Hydraulic Pump Valve Model : VE32D

Hydraulic Pump Valve Operation : Solenoid

Hydraulic Pump Valve Type and Pump Operation : 3-way, 2-position, Dump

Hydraulic Pump Maximum Flow At Rated Pressure Liter : 0.27

PLG: default Price Group List Price : 1

Description

  • 0,56 kW induction motor for long life and quiet operation
  • 71 to 79 dBA across the pressure range
  • 6,8 liter, steel hydraulic oil reservoir offers capacity and cool operation for wide range of applications
  • IP54 protection
  • Heavy duty bearings extend pump life by reducing heat, improving lubrication and reducing wear
  • Replaceable piston check valves increase service life of major pump components
