ZA4420MX

ZA4420MX

SKU: ZA4420MX Categories: , , Brand:
Login to purchase
Enquire for this product

Maximum Operating Pressure psi : 10,000

Maximum Operating Pressure bar : 700

Series : ZA

Unit Height Shipping Oracle ERP : 34

Unit Length Shipping Oracle ERP : 31

Unit Width Shipping Oracle ERP : 25

Dimension A mm : 330

Dimension B mm : 180

Dimension C mm : 414

Dimension D mm : 421

Dimension E mm : 500

Dimension H mm : 467

Weight Kgs : 52

Hydraulic Pump Air Consumption Scfm : 20 - 100

Hydraulic Pump Air Pressure Range Psi : 60 - 100

Hydraulic Pump Cylinder Compatability : Double-acting

Hydraulic Pump Maximum Flow Rate Ranges at Rated Pressure In 3 min : 60 - 119

Hydraulic Pump Maximum Flow Rate Ranges at Rated Pressure L min : 0,98 - 1,95

Hydraulic Pump Maximum Flowat Rated Pressure : 1,3 l/min

Hydraulic Pump Maximum Operating Pressure Ranges Bar : 700

Hydraulic Pump Maximum Operating Pressure Ranges Psi : 10,000

Hydraulic Pump Output Flow Rate 10000 Psi In 3min : 80

Hydraulic Pump Output Flow Rate 100 psi In 3min : 850

Hydraulic Pump Output Flow Rate 350 bar In 3 min : 1,8

Hydraulic Pump Output Flow Rate 350 bar L min : 1,8

Hydraulic Pump Output Flow Rate 5000 Psi In 3 min : 110

Hydraulic Pump Output Flow Rate 50 bar In 3 min : 11,0

Hydraulic Pump Output Flow Rate 50 bar L min : 11,0

Hydraulic Pump Output Flow Rate 700 Psi In 3 min : 675

Hydraulic Pump Output Flow Rate 700 bar In 3 min : 1,3

Hydraulic Pump Output Flow Rate 700 bar L min : 1,3

Hydraulic Pump Output Flow Rate 7 bar In 3 min : 14,0

Hydraulic Pump Output Flow Rate 7 bar L min : 14,0

Hydraulic Pump Control : Manual

Hydraulic Pump Power Source : Air

Hydraulic Pump Relief Valve Adjustment Range bar : 70 - 700

Hydraulic Pump Reservoir Capacity cm3 : 20,000

Hydraulic Pump Sound Leveld Ba : 94 - 97

Hydraulic Pump Usable Oil capacity Gal : 5

Hydraulic Pump Usable Oil Capacity Litres : 20,0

Hydraulic Pump Valve Function : Advance / Hold / Retract

Hydraulic Pump Valve Model : VM43

Hydraulic Pump Valve Operation : Manual

Hydraulic Pump Air Consumption L min : 2,840

Hydraulic Pump Maximum Flow At Rated Pressure Liter : 1

Hydraulic Pump Maximum Flow At Rated Pressure Metric : 1,3 l/min

Hydraulic Pump Valve Type : 4-way, 3-position, Tandem Center

PLG: default Price Group List Price : 1

Description

  • High Performance, Zero Emission Hydraulic Power Pack
  • Lithium-ion battery driven stressing pump
  • 3 Stage pump leading to improved efficiency
  • Steel manual operating valve with pressure hold function
  • Safety key to safely leave the pump unattended during breaks
  • Pressure release valve V182 included
  • Pump weight 34,8 kg (excluding battery)
  • Reduced Noise Level 75 dBA max
  • Advanced brushless 1,0 kW motor
  • Exchangeable battery and less maintenance due to modular parts
  • Network Rail Certificate of Acceptance PA05-06958
