ZA4208TX-QR0P
ZA4208TX-QR0P - Image 2
ZA4208TX-QR0P - Image 3
ZA4208TX-QR0P - Image 4

ZA4208TX-QR0P

SKU: ZA4208TX-QR0P Categories: , , Brand:
Login to purchase
Enquire for this product

Maximum Operating Pressure psi : 10,000

Maximum Operating Pressure bar : 700

Series : ZA4T

Compatible Products : S1500X,S1500PX,S3000X,S3000PX,S6000X,S6000PX,S11000X,S11000PX,S25000X,S25000PX,W2000X,W2000X,W4000X,W4000X,W8000X,W8000X,W15000X,W15000X,W22000X,W22000X,W35000X,W35000X,RSL1500,RSL3000,RSL5000,RSL8000,RSL11000,RSL19000,RSL28000,DSX1500,DSX3000,DSX5000,DSX11000,DSX25000,HMT1500,HMT3500,HMT7500,HMT13000

Weight Kgs : 52,2

Hydraulic Pump Air Consumption Scfm : 20-100

Hydraulic Pump Air Pressure Range Psi : 60-100

Hydraulic Pump Air Pressure Range bar : 4,1-6,9

Hydraulic Pump Dimension Lx Wx H mm : 493x318x521

Hydraulic Pump For Use With Torque Wrenches : For use with all Enerpac torque wrenches

Hydraulic Pump Maximum Flow Rate Ranges at Rated Pressure In 3 min : 60 - 119

Hydraulic Pump Maximum Flow Rate Ranges at Rated Pressure L min : 0,98 - 1,95

Hydraulic Pump Maximum Operating Pressure Ranges Bar : 700

Hydraulic Pump Maximum Operating Pressure Ranges Psi : 10,000

Hydraulic Pump Output Flow Rate 10000 Psi In 3min : 60

Hydraulic Pump Output Flow Rate 100 psi In 3min : 600

Hydraulic Pump Output Flow Rate 350 bar L min : 1,3

Hydraulic Pump Output Flow Rate 5000 Psi In 3 min : 80

Hydraulic Pump Output Flow Rate 700 bar L min : 1,0

Hydraulic Pump Output Flow Rate 7 bar L min : 10,0

Hydraulic Pump Output Flow Rate At Maximum Pressure In 3 min : 60

Hydraulic Pump Pressure Rating bar : 700

Hydraulic Pump Pressure Rating psi : 10,000

Hydraulic Pump Control : Pendant

Hydraulic Pump Power Source : Air

Hydraulic Pump Relief Valve Adjustment Range Psi : 2,000 - 10,000

Hydraulic Pump Relief Valve Adjustment Range bar : 138 - 700

Hydraulic Pump Reservoir Capacity Litres : 6,8

Hydraulic Pump Reservoir Capacity cm3 : 6,800

Hydraulic Pump Reservoir Capacity gal : 2

Hydraulic Pump Sound Leveld Ba : 87 - 90

Hydraulic Pump Usable Oil capacity Gal : 1

Hydraulic Pump Usable Oil Capacity Litres : 2,7

Hydraulic Pump Air Consumption L min : 600-2840

Hydraulic Pump Maximum Flow At Rated Pressure Liter : 0.4

PLG: default Price Group List Price : 1

Description

  • ATEX 95 certified for use in potentially explosive atmospheres
  • The Enerpac ZA4-series air pumps are tested and certified according to the Equipment Directive 94 / 9 / EC “ATEX Directive” for equipment and protective systems intended for use in potentially explosive atmospheres
  • Features Z-Class high efficiency pump design, higher oil flow and bypass pressure
  • Two-speed operation reduces cycle time for improved productivity
  • User adjustable relief valve built-in on manual valves. Oil ports on valves are 3/8″ NPTF
  • Optional heat exchanger warms exhaust air to prevent freezing and cools the oil
  • Oil level indicators on 4 and 6,6 litres reservoirs

Additional information

Weight 63 kg
