Maximum Operating Pressure psi : 10,000
Maximum Operating Pressure bar : 700
Series : XA
Unit Height Shipping Oracle ERP : 11
Unit Length Shipping Oracle ERP : 14
Unit Width Shipping Oracle ERP : 16
Weight Kgs : 10,3
Hydraulic Pump Air Consumption Scfm : Oct-35
Hydraulic Pump Air Pressure Range Psi : 30 - 125
Hydraulic Pump Air Pressure Range bar : 2,1 - 8,6
Hydraulic Pump Cylinder Compatability : Double-acting
Hydraulic Pump Dimension H1 mm : 152
Hydraulic Pump Dimension L mm : 279
Hydraulic Pump Maximum Flow Rate Ranges at Rated Pressure In 3 min : 0 - 20
Hydraulic Pump Maximum Flow Rate Ranges at Rated Pressure L min : 0 - 0,34
Hydraulic Pump Maximum Flowat Rated Pressure : 0,25 l/min
Hydraulic Pump Maximum Operating Pressure Ranges Bar : 700
Hydraulic Pump Maximum Operating Pressure Ranges Psi : 10,000
Hydraulic Pump Output Flow Rate Load In 3 Min : 15
Hydraulic Pump Output Flow Rate Load L min : 0,25
Hydraulic Pump Output Flow Rate No Load In 3 min : 120
Hydraulic Pump Output Flow Rate No Load L min : 2,0
Hydraulic Pump Control : Manual
Hydraulic Pump Power Source : Air
Hydraulic Pump Reservoir Capacity cm3 : 1,000
Hydraulic Pump Usable Oil Capacity Litres : 1,0
Hydraulic Pump Valve Function : Advance / Hold / Retract
Hydraulic Pump Valve Operation : Manual
Hydraulic Pump Air Consumption L min : 283 - 991
Hydraulic Pump Maximum Flow At Rated Pressure Liter : 0.25
Hydraulic Pump Maximum Flow At Rated Pressure Metric : 0,25 l/min
Hydraulic Pump Valve Type : 4-way, 3-position
PLG: default Price Group List Price : 1
