Additional information
Weight | 8.278 kg |
---|
Maximum Operating Pressure psi : 10,000
Series : W - Cassette
Compatible Products : W4000x,W4215R200,W4215R203,W4215R206,W4215R209
Dimension A mm : 136
Dimension B mm : 167
Dimension C mm : 178
Dimension D mm : 41
Dimension E mm : 33
Dimension F mm : 20
Height Dimension mm : 196
Length Dimension mm : 233
Weight Kgs : 4.1
Width Dimension mm : 41
Torque Wrench AF Size Facet mm : 75
Torque Wrench Maximum Speed RPMs : 5661
Torque Wrench Nominal Torque Nm : 5661
Torque Wrench compatible Drive Units : W4000X
Torque Wrench compatible Reducers : W4215R200,W4215R203,W4215R206,W4215R209
Torque Wrench hexagon Size S mm : 75
Torque Wrench minimum Torque Nm : 566
Torque Wrench nose Radius H mm : 55,3
PLG: default Price Group List Price : 1
Weight | 8.278 kg |
---|
