Maximum Operating Pressure psi : 10,000
Series : W - Cassette
Unit Height Shipping Oracle ERP : 7
Unit Length Shipping Oracle ERP : 15
Unit Width Shipping Oracle ERP : 14
Compatible Products : W4000x,W4212R202,W4212R203,W4212R206
Dimension A mm : 136
Dimension B mm : 167
Dimension C mm : 178
Dimension D mm : 41
Dimension E mm : 33
Dimension F mm : 20
Height Dimension mm : 192
Length Dimension mm : 231
Weight Kgs : 4
Width Dimension mm : 41
Torque Wrench AF Size Facet mm : 70
Torque Wrench Maximum Speed RPMs : 5661
Torque Wrench Nominal Torque Nm : 5661
Torque Wrench compatible Drive Units : W4000X
Torque Wrench compatible Reducers : W4212R202,W4212R203,W4212R206
Torque Wrench hexagon Size S mm : 70
Torque Wrench minimum Torque Nm : 566
Torque Wrench nose Radius H mm : 52,5
PLG: default Price Group List Price : 1
