SWI1214TMSTDSPB

SKU: SWI1214TMSTDSPB Categories: , , Brand:

Series : SWi

Capacity KN : 140

Capacity Metric Tons : 14

Height Dimension mm : 152

Length Dimension mm : 290

Weight Kgs : 13

Spreader case Dimensions Mm : 580 x 330 x 165

Spreader jaw Width Mm : 60,0

Spreader maximum Operating Torque Nm : 175

Spreader maximum Spread Mm : 103.5

Spreader tip Clearance Mm : 6

PLG: default Price Group List Price : 1

Description

  • Exclusive overload protection from load shifts
  • Pistol-grip handle for balanced carrying and fast setup
  • Solid cast base provides more surface contact area, and a large grooved toe provides stable jacking
  • Inverted hard chrome piston design keeps water and dirt out, extending the life of the jack
  • Low handle effort allows one-man operation for lifting heavy loads
  • Anti-kickback design reduces risk of injury to operator if load is inadvertently released
  • All models can lift from toe or cap, ideal for spreading and jacking applications
  • Ideal for tough lifting applications; such as frogs, turn-outs, diamonds and concrete tie sections
  • Inverted Design keeps water and dirt out of the jack, increasing performance and life cycle. Allows lifting from toe or cap.

Additional information

Weight 13.6 kg
