Maximum Operating Pressure psi : 10,000
Maximum Operating Pressure bar : 700
Series : SHC
Stroke mm : 1500
Capacity KN : 1078
Capacity Metric Tons : 110
Compatible Products : SHP414SJ,SHP414SW,SHP421SJ,SHP421SW,SHH25
Dimension A mm : 2355
Dimension B mm : 3855
Dimension E mm : 85
Dimension H mm : 405
Dimension J mm : 124
Weight Kgs : 1235
Hydraulic Cylinders Dimension F1 mm : 205
Hydraulic Cylinders Dimension D1 mm : 780
Hydraulic Cylinders Dimension D2 mm : 315
Hydraulic Cylinders dimension F2 mm : 174
PLG: default Price Group List Price : 1
