Maximum Operating Pressure psi : 10,150
Maximum Operating Pressure bar : 700
Series : RT
Stroke mm : 300
Dimension K mm : 53
Weight Kgs : 21,8
Hydraulic Cylinders Base to Advance Port H mm : 23
Hydraulic Cylinders Collapsed Height A mm : 317
Hydraulic Cylinders Extended Height B mm : 617
Hydraulic Cylinders Maximum Cylinder Capacity Advance kn : 198
Hydraulic Cylinders Maximum Operating Pressure Ranges psi : 10,000
Hydraulic Cylinders Outside Diameter D mm : 125
Hydraulic Cylinders Saddle Diameter J1 mm : 60
Hydraulic Cylinders Stage 1 Capacity Kn : 496
Hydraulic Cylinders Stage 1 Stroke S1 mm : 150
Hydraulic Cylinders Stage 2 Capacity kn : 198
Hydraulic Cylinders Stage 2 Stroke S2 mm : 150
Hydraulic Cylinders Stage 3 Stroke S3 mm : -
Hydraulic Cylinders Collapsed Height A Ranges Mm : 255 - 381
Hydraulic Cylinders Dimension L mm : 66
Hydraulic Cylinders Oil Capacity Advance Cm3 : 1487
Hydraulic Cylinders Return Type : Single-Acting, Load Return
Hydraulic Cylinders Saddle Diameter J mm : 60
Hydraulic Cylinders Stroke Ranges mm : 290 - 379
PLG: default Price Group List Price : 1
