Maximum Operating Pressure psi : 10,150
Maximum Operating Pressure bar : 700
Series : RT
Stroke mm : 435
Dimension K mm : 73
Weight Kgs : 40,3
Hydraulic Cylinders Base to Advance Port H mm : 27
Hydraulic Cylinders Collapsed Height A mm : 345
Hydraulic Cylinders Extended Height B mm : 780
Hydraulic Cylinders Maximum Cylinder Capacity Advance kn : 166
Hydraulic Cylinders Maximum Operating Pressure Ranges psi : 10,000
Hydraulic Cylinders Outside Diameter D mm : 170
Hydraulic Cylinders Saddle Diameter J1 mm : 80
Hydraulic Cylinders Stage 1 Capacity Kn : 929
Hydraulic Cylinders Stage 1 Stroke S1 mm : 145
Hydraulic Cylinders Stage 2 Capacity kn : 397
Hydraulic Cylinders Stage 2 Stroke S2 mm : 145
Hydraulic Cylinders Stage 3 Stroke S3 mm : 145
Hydraulic Cylinders Collapsed Height A Ranges Mm : 255 - 381
Hydraulic Cylinders Dimension L mm : 85
Hydraulic Cylinders Oil Capacity Advance Cm3 : 3092
Hydraulic Cylinders Return Type : Single-Acting, Load Return
Hydraulic Cylinders Saddle Diameter J mm : 80
Hydraulic Cylinders Stroke Ranges mm : > 380
PLG: default Price Group List Price : 1
