Maximum Operating Pressure psi : 10,000
Maximum Operating Pressure bar : 700
Series : RCH
Stroke mm : 76
Unit Height Shipping Oracle ERP : 3
Unit Length Shipping Oracle ERP : 6
Unit Width Shipping Oracle ERP : 9
Weight Kgs : 4,4
Hydraulic Cylinders Base Mounting Holes Thread V : 5/16"-18 unc
Hydraulic Cylinders Base to Advance Port H mm : 25
Hydraulic Cylinders Collapsed Height A mm : 184
Hydraulic Cylinders Collar Thread Length X mm : 30
Hydraulic Cylinders Collar Thread W mm : 2 3/4" - 16
Hydraulic Cylinders Cylinder Effective Area Advance cm2 : 17,9
Hydraulic Cylinders Extended Height B mm : 260
Hydraulic Cylinders Maximum Cylinder Capacity Advance kn : 125
Hydraulic Cylinders Maximum Operating Pressure Ranges psi : 10,000
Hydraulic Cylinders Outside Diameter D mm : 69
Hydraulic Cylinders Collapsed Height A Ranges Mm : 128 - 254
Hydraulic Cylinders Oil Capacity Advance Cm3 : 136
Hydraulic Cylinders Return Type : Single-Acting, Spring Return
Hydraulic Cylinders Stroke Ranges mm : 48 - 94
PLG: default Price Group List Price : 1
