RCH1003

SKU: RCH1003 Categories: , , Brand:
Login to purchase
Enquire for this product

Maximum Operating Pressure psi : 10,000

Maximum Operating Pressure bar : 700

Series : RCH

Stroke mm : 76

Unit Height Shipping Oracle ERP : 11

Unit Length Shipping Oracle ERP : 13

Unit Width Shipping Oracle ERP : 11

Weight Kgs : 63,0

Hydraulic Cylinders Base Mounting Holes Thread V : 5/8"-11 unc

Hydraulic Cylinders Base to Advance Port H mm : 38

Hydraulic Cylinders Collapsed Height A mm : 254

Hydraulic Cylinders Collar Thread Length X mm : 60

Hydraulic Cylinders Collar Thread W mm : 8 3/8" - 12

Hydraulic Cylinders Cylinder Effective Area Advance cm2 : 133,0

Hydraulic Cylinders Extended Height B mm : 330

Hydraulic Cylinders Maximum Cylinder Capacity Advance kn : 931

Hydraulic Cylinders Maximum Operating Pressure Ranges psi : 10,000

Hydraulic Cylinders Outside Diameter D mm : 212

Hydraulic Cylinders Plunger Thread Length P mm : 25

Hydraulic Cylinders Saddle Diameter J1 mm : 126

Hydraulic Cylinders Collapsed Height A Ranges Mm : 255 - 381

Hydraulic Cylinders Oil Capacity Advance Cm3 : 1011

Hydraulic Cylinders Return Type : Single-Acting, Spring Return

Hydraulic Cylinders Saddle Diameter J mm : 126

Hydraulic Cylinders Stroke Ranges mm : 48 - 94

PLG: default Price Group List Price : 1

Description

  • Constant torque output provides accuracy of +/- 3% across full stroke.

Additional information

Weight 56.6 kg
