Maximum Operating Pressure psi : 10,000
Maximum Operating Pressure bar : 700
Series : RC
Stroke mm : 177
Unit Height Shipping Oracle ERP : 4
Unit Length Shipping Oracle ERP : 7
Unit Width Shipping Oracle ERP : 13
Weight Kgs : 2,4
Hydraulic Cylinders Base Mounting Holes Bolt Circle U mm : 25
Hydraulic Cylinders Base Mounting Holes Thread Depth Z mm : 14
Hydraulic Cylinders Base Mounting Holes Thread V : 1/4"- 20 un
Hydraulic Cylinders Base to Advance Port H mm : 19
Hydraulic Cylinders Collapsed Height A mm : 273
Hydraulic Cylinders Collar Thread Length X mm : 28
Hydraulic Cylinders Collar Thread W mm : 1 1/2" - 16 un
Hydraulic Cylinders Cylinder Effective Area Advance cm2 : 6,4
Hydraulic Cylinders Extended Height B mm : 450
Hydraulic Cylinders Maximum Cylinder Capacity Advance kn : 45
Hydraulic Cylinders Maximum Operating Pressure Ranges psi : 10,000
Hydraulic Cylinders Outside Diameter D mm : 38
Hydraulic Cylinders Plunger Thread Length P mm : 16
Hydraulic Cylinders Saddle Diameter J1 mm : 25
Hydraulic Cylinders Saddle Protrusion from Plunger K1 mm : 6
Hydraulic Cylinders Collapsed Height A Ranges Mm : 255 - 381
Hydraulic Cylinders Oil Capacity Advance Cm3 : 115
Hydraulic Cylinders Return Type : Single-Acting, Spring Return
Hydraulic Cylinders Saddle Diameter J mm : 25
Hydraulic Cylinders Saddle Protrusion From Plunger K mm : 6
Hydraulic Cylinders Stroke Ranges mm : 175 - 239
