Maximum Operating Pressure psi : 10,000
Maximum Operating Pressure bar : 700
Series : RC
Stroke mm : 50
Unit Height Shipping Oracle ERP : 6
Unit Length Shipping Oracle ERP : 6
Unit Width Shipping Oracle ERP : 9
Weight Kgs : 6,4
Hydraulic Cylinders Base Mounting Holes Bolt Circle U mm : 59
Hydraulic Cylinders Base Mounting Holes Thread Depth Z mm : 19
Hydraulic Cylinders Base Mounting Holes Thread V : 1/2"- 13 un
Hydraulic Cylinders Base to Advance Port H mm : 25
Hydraulic Cylinders Collapsed Height A mm : 165
Hydraulic Cylinders Collar Thread Length X mm : 49
Hydraulic Cylinders Collar Thread W mm : 3 5/16" - 12 un
Hydraulic Cylinders Cylinder Effective Area Advance cm2 : 33,3
Hydraulic Cylinders Extended Height B mm : 215
Hydraulic Cylinders Maximum Cylinder Capacity Advance kn : 232
Hydraulic Cylinders Maximum Operating Pressure Ranges psi : 10,000
Hydraulic Cylinders Optional Tilt Saddle Addition To Collapsed Height A1 mm : 15
Hydraulic Cylinders Outside Diameter D mm : 86
Hydraulic Cylinders Plunger Thread Length P mm : 25
Hydraulic Cylinders Saddle Diameter J1 mm : 50
Hydraulic Cylinders Saddle Maximum Tilt Angle Radius Degrees : 5
Hydraulic Cylinders Saddle Protrusion from Plunger K1 mm : 10
Hydraulic Cylinders Collapsed Height A Ranges Mm : 128 - 254
Hydraulic Cylinders Oil Capacity Advance Cm3 : 166
Hydraulic Cylinders Return Type : Single-Acting, Spring Return
Hydraulic Cylinders Saddle Diameter J mm : 51
Hydraulic Cylinders Saddle Protrusion From Plunger K mm : 10
Hydraulic Cylinders Stroke Ranges mm : 48 - 94
PLG: default Price Group List Price : 1
