Maximum Operating Pressure psi : 10,000
Maximum Operating Pressure bar : 700
Series : PR
Stroke mm : 406
Capacity KN : 889
Dimension C mm : 457
Weight Kgs : 231
Wheeled Jack Extension System Note : Maximum Additional Stack Height is based on one 457 mm and one 76 mm spacer
Wheeled Jack Power Source : Air
Wheeled Jack Valve Type : Pneumatic
Wheeled Jack collapsed Height A Mm : 660
Wheeled Jack handle Height mm : 1422
Wheeled Jack maximum Additional Stack Height Using Optional Extension System mm : 533
Wheeled Jack outside Diameter B mm : 178
Wheeled Jack power Source Spec Metric : Air Pump (1416 l/min air consumption at 5,5 bar)
Wheeled Jack saddle Diameter D mm : 102
PLG: default Price Group List Price : 1
