PL20025ASA

PL20025ASA

SKU: PL20025ASA Categories: , , Brand:
Login to purchase
Enquire for this product

Maximum Operating Pressure psi : 10,000

Maximum Operating Pressure bar : 700

Series : PL

Stroke mm : 622

Capacity KN : 1779

Weight Kgs : 599

Wheeled Jack Cylinder Lifting Speed Note : Cylinder lifting speed is dependant on available airflow, regulator setting, pump speed and load weight

Wheeled Jack Power Source : Air

Wheeled Jack collapsed Height A Mm : 1778

Wheeled Jack collapsed Height B Mm : 1156

Wheeled Jack cylinder Lifting Speed No Load Mm min : 61

Wheeled Jack cylinder Lifting Speed With Load Mm min : 51

Wheeled Jack extended Height A mm : 1778

Wheeled Jack front Base Width mm : 599

Wheeled Jack handle Down Height mm : 980

Wheeled Jack handle Height mm : 1626

Wheeled Jack handle Up Height mm : 1626

Wheeled Jack handle Width mm : 399

Wheeled Jack maximum Additional Stack Height Using Optional Extension System mm : 229

Wheeled Jack outside Diameter B mm : 1156

Wheeled Jack outside Diameter mm : 368

Wheeled Jack power Source Spec Metric : Air Pump (3681 - 4247 l/min, 3,8 - 6,9 bar)

Wheeled Jack rear Wheel Width mm : 645

wheeled Jack saddle Diameter mm : 127

wheeled Jack total Length Mm : 2283

PLG: default Price Group List Price : 1
