Maximum Operating Pressure psi : 10,000
Maximum Operating Pressure bar : 700
Series : PAMG
Unit Height Shipping Oracle ERP : 12
Unit Length Shipping Oracle ERP : 9
Unit Width Shipping Oracle ERP : 16
Dimension A mm : 396
Dimension B mm : 201
Dimension C mm : 267
Dimension D mm : 230
Dimension E mm : 102
Dimension F mm : 36
Dimension H mm : 132
Dimension J mm : 152
Weight Kgs : 12,7
Hydraulic Pump Air Pressure Range bar : 2,8 - 8,8
Hydraulic Pump Cylinder Compatability : Double-acting
Hydraulic Pump Dimension L mm : 112
Hydraulic Pump Dimension M mm : 405
Hydraulic Pump Maximum Flow Rate Ranges at Rated Pressure In 3 min : 0 - 20
Hydraulic Pump Maximum Flow Rate Ranges at Rated Pressure L min : 0 - 0,34
Hydraulic Pump Maximum Flowat Rated Pressure : 0,16 l/min
Hydraulic Pump Maximum Operating Pressure Ranges Bar : 700
Hydraulic Pump Maximum Operating Pressure Ranges Psi : 10,000
Hydraulic Pump Output Flow Rate Load L min : 0,16
Hydraulic Pump Output Flow Rate No Load L min : 1,0
Hydraulic Pump Control : Manual
Hydraulic Pump Power Source : Air
Hydraulic Pump Reservoir Capacity cm3 : 3770
Hydraulic Pump Usable Oil Capacity cm3 : 3770
Hydraulic Pump Valve Function : Advance / Hold / Retract
Hydraulic Pump Valve Model : VM4
Hydraulic Pump Valve Operation : Manual
Hydraulic Pump Air Consumption L min : 340
Hydraulic Pump Maximum Flow At Rated Pressure Liter : 0.16
Hydraulic Pump Maximum Flow At Rated Pressure Metric : 0,16 l/min
Hydraulic Pump Valve Type : 4-way, 3-position, Tandem Center
