PAM1042

PAM1042

SKU: PAM1042 Categories: , , Brand:
Login to purchase
Enquire for this product

Maximum Operating Pressure psi : 10,000

Maximum Operating Pressure bar : 700

Series : PAM

Unit Height Shipping Oracle ERP : 17

Unit Length Shipping Oracle ERP : 20

Unit Width Shipping Oracle ERP : 13

Weight Kgs : 27,2

Hydraulic Pump Air Consumption Scfm : 18

Hydraulic Pump Air Pressure Range Psi : 60 - 120

Hydraulic Pump Air Pressure Range bar : 4,1 - 8,3

Hydraulic Pump Cylinder Compatability : Double-acting

Hydraulic Pump Maximum Flow Rate Ranges at Rated Pressure In 3 min : 0 - 20

Hydraulic Pump Maximum Flow Rate Ranges at Rated Pressure L min : 0 - 0,34

Hydraulic Pump Maximum Flowat Rated Pressure : 0,15 l/min

Hydraulic Pump Maximum Operating Pressure Ranges Bar : 700

Hydraulic Pump Maximum Operating Pressure Ranges Psi : 10,000

Hydraulic Pump Output Flow Rate 1st Stage In 3 min : 650

Hydraulic Pump Output Flow Rate 2nd Stage In 3 min : 9

Hydraulic Pump Control : Manual

Hydraulic Pump Power Source : Air

Hydraulic Pump Reservoir Capacity Litres : 8

Hydraulic Pump Reservoir Capacity cm3 : 7600

Hydraulic Pump Reservoir Size Ranges Liters : 8,0 - 19,9

Hydraulic Pump Sound Leveld Ba : 87

Hydraulic Pump Usable Oil capacity Gal : 2

Hydraulic Pump Usable Oil Capacity Litres : 7,6

Hydraulic Pump Valve Function : Advance / Hold / Retract

Hydraulic Pump Valve Model : VM4

Hydraulic Pump Air Consumption L min : 510

Hydraulic Pump Maximum Flow At Rated Pressure Liter : 0.15

Hydraulic Pump Maximum Flow At Rated Pressure Metric : 0,15 l/min

Hydraulic Pump Output Flow Rate 1st Stage L min : 10,65

Hydraulic Pump Output Flow Rate 2nd Stage L min : 0,15

Hydraulic Pump Valve Type : 4-way, 3-position, Tandem Center

PLG: default Price Group List Price : 1

Additional information

Weight 30.315 kg
