Maximum Operating Pressure psi : 10,000
Maximum Operating Pressure bar : 700
Series : PAM
Unit Height Shipping Oracle ERP : 13
Unit Length Shipping Oracle ERP : 19
Unit Width Shipping Oracle ERP : 17
Weight Kgs : 22,7
Hydraulic Pump Air Consumption Scfm : 18
Hydraulic Pump Air Pressure Range Psi : 60 - 120
Hydraulic Pump Air Pressure Range bar : 4,1 - 8,3
Hydraulic Pump Cylinder Compatability : Single-acting
Hydraulic Pump Maximum Flow Rate Ranges at Rated Pressure In 3 min : 0 - 20
Hydraulic Pump Maximum Flow Rate Ranges at Rated Pressure L min : 0 - 0,34
Hydraulic Pump Maximum Flowat Rated Pressure : 0,15 l/min
Hydraulic Pump Maximum Operating Pressure Ranges Bar : 700
Hydraulic Pump Maximum Operating Pressure Ranges Psi : 10,000
Hydraulic Pump Output Flow Rate 1st Stage In 3 min : 650
Hydraulic Pump Output Flow Rate 2nd Stage In 3 min : 9
Hydraulic Pump Control : Manual
Hydraulic Pump Power Source : Air
Hydraulic Pump Reservoir Capacity Litres : 4
Hydraulic Pump Reservoir Capacity cm3 : 2600
Hydraulic Pump Reservoir Size Ranges Liters : 4,0 - 7,9
Hydraulic Pump Sound Leveld Ba : 87
Hydraulic Pump Usable Oil capacity Gal : 0.7
Hydraulic Pump Usable Oil Capacity Litres : 2,6
Hydraulic Pump Valve Function : Advance / Retract
Hydraulic Pump Valve Model : VM2
Hydraulic Pump Air Consumption L min : 510
Hydraulic Pump Maximum Flow At Rated Pressure Liter : 0.15
Hydraulic Pump Maximum Flow At Rated Pressure Metric : 0,15 l/min
Hydraulic Pump Output Flow Rate 1st Stage L min : 10,65
Hydraulic Pump Output Flow Rate 2nd Stage L min : 0,15
Hydraulic Pump Valve Type : 3-way, 2-position
PLG: default Price Group List Price : 1
