P802

SKU: P802 Categories: , , Brand:
Login to purchase
Enquire for this product

Maximum Operating Pressure psi : 10,000

Maximum Operating Pressure bar : 700

Series : P

Unit Height Shipping Oracle ERP : 9

Unit Length Shipping Oracle ERP : 24

Unit Width Shipping Oracle ERP : 8

Dimension A mm : 337

Dimension B mm : 552

Dimension C mm : 45

Dimension D mm : 133

Dimension E mm : 35

Dimension H mm : 527

Dimension J mm : 30

Weight Kgs : 8,2

Hydraulic Pump Cylinder Compatability : Single-acting

Hydraulic Pump Dimension L mm : 228

Hydraulic Pump Dimension N mm : 181

Hydraulic Pump Dimension P mm : 153

Hydraulic Pump Dimension Q mm : 35

Hydraulic Pump Dimension S mm : 10

Hydraulic Pump Maximum Flow Rate Ranges at Rated Pressure In 3 min : 0 - 20

Hydraulic Pump Maximum Flowat Rated Pressure : 2,47 cm3/stroke

Hydraulic Pump Maximum Handle Effort kg : 43,1

Hydraulic Pump Maximum Operating Pressure Ranges Bar : 700

Hydraulic Pump Maximum Operating Pressure Ranges Psi : 10,000

Hydraulic Pump Oil Displacement Per Stroke 1st Stage cm3 : 39,33

Hydraulic Pump Oil Displacement Per Stroke 2nd Stage cm3 : 2,47

Hydraulic Pump Piston Stroke mm : 25,4

Hydraulic Pump Pressure Rating 1st Stage Psi : 400

Hydraulic Pump Pressure Rating 1st Stage bar : 27

Hydraulic Pump Pressure Rating 2nd Stage bar : 700

Hydraulic Pump Pressure Rating 2nd Stage Psi : 10,000

Hydraulic Pump Power Source : Manual

Hydraulic Pump Reservoir Capacity cm3 : 2,540

Hydraulic Pump Usable Oil Capacity cm3 : 2540

Hydraulic Pump Valve Operation : Manual

Hydraulic Pump Maximum Flow At Rated Pressure Liter : 0.00247

Hydraulic Pump Maximum Flow At Rated Pressure Metric : 2,47 cm3/stroke

PLG: default Price Group List Price : 1

Description

  • Spacers – Minimize gap between load cap and lifting point to maximize hydraulic stroke of the jack

Additional information

Weight 7.137 kg
