Maximum Operating Pressure psi : 3,000
Maximum Operating Pressure bar : 200
Series : P
Unit Height Shipping Oracle ERP : 9
Unit Length Shipping Oracle ERP : 25
Unit Width Shipping Oracle ERP : 7
Dimension A mm : 52
Dimension B mm : 92
Dimension C mm : 181
Dimension D mm : 200
Dimension E mm : 57
Dimension H mm : 610
Dimension J mm : 29
Weight Kgs : 5,4
Hydraulic Pump Cylinder Compatability : Single-acting
Hydraulic Pump Dimension L mm : 160
Hydraulic Pump Dimension M mm : 129
Hydraulic Pump Dimension S mm : 9
Hydraulic Pump Maximum Flow Rate Ranges at Rated Pressure In 3 min : 0 - 20
Hydraulic Pump Maximum Flowat Rated Pressure : 4,10 cm3/stroke
Hydraulic Pump Maximum Handle Effort kg : 27
Hydraulic Pump Maximum Operating Pressure Ranges Bar : < 350
Hydraulic Pump Maximum Operating Pressure Ranges Psi : < 5,000
Hydraulic Pump Oil Displacement Per Stroke 1st Stage cm3 : 4,10
Hydraulic Pump Oil Displacement Per Stroke 2nd Stage cm3 : -
Hydraulic Pump Piston Stroke mm : 25,4
Hydraulic Pump Pressure Rating 1st Stage Psi : 3,000
Hydraulic Pump Pressure Rating 1st Stage bar : 200
Hydraulic Pump Pressure Rating 2nd Stage bar : -
Hydraulic Pump Pressure Rating 2nd Stage Psi : -
Hydraulic Pump Power Source : Manual
Hydraulic Pump Reservoir Capacity cm3 : 819
Hydraulic Pump Usable Oil Capacity cm3 : 819
Hydraulic Pump Valve Operation : Manual
Hydraulic Pump Maximum Flow At Rated Pressure Liter : 0.0041
Hydraulic Pump Maximum Flow At Rated Pressure Metric : 4,10 cm3/stroke
PLG: default Price Group List Price : 1
