Maximum Operating Pressure psi : 5,000
Maximum Operating Pressure bar : 350
Series : P
Unit Height Shipping Oracle ERP : 10
Unit Length Shipping Oracle ERP : 7
Unit Width Shipping Oracle ERP : 22
Dimension A mm : 152
Dimension B mm : 173
Dimension C mm : 152
Dimension D mm : 240
Weight Kgs : 16,8
Hydraulic Pump Cylinder Compatability : Single-acting
Hydraulic Pump Dimension L mm : 684
Hydraulic Pump Dimension M mm : 200
Hydraulic Pump Dimension S mm : 10
Hydraulic Pump Maximum Flow Rate Ranges at Rated Pressure In 3 min : 0 - 20
Hydraulic Pump Maximum Flowat Rated Pressure : 4,75 cm3/stroke
Hydraulic Pump Maximum Handle Effort kg : 27
Hydraulic Pump Maximum Operating Pressure Ranges Bar : 350
Hydraulic Pump Maximum Operating Pressure Ranges Psi : 5,000
Hydraulic Pump Oil Displacement Per Stroke 1st Stage cm3 : 4,75
Hydraulic Pump Oil Displacement Per Stroke 2nd Stage cm3 : -
Hydraulic Pump Piston Stroke mm : 38,1
Hydraulic Pump Pressure Rating 1st Stage Psi : 5,000
Hydraulic Pump Pressure Rating 1st Stage bar : 350
Hydraulic Pump Pressure Rating 2nd Stage bar : -
Hydraulic Pump Pressure Rating 2nd Stage Psi : -
Hydraulic Pump Power Source : Manual
Hydraulic Pump Reservoir Capacity cm3 : 3277
Hydraulic Pump Usable Oil Capacity cm3 : 3277
Hydraulic Pump Valve Operation : Manual
Hydraulic Pump Maximum Flow At Rated Pressure Liter : 0.00475
Hydraulic Pump Maximum Flow At Rated Pressure Metric : 4,75 cm3/stroke
