P464
P464 - Image 2
P464 - Image 3
P464 - Image 4
P464 - Image 5

P464

SKU: P464 Categories: , , Brand:
Login to purchase
Enquire for this product

Maximum Operating Pressure psi : 10,000

Maximum Operating Pressure bar : 700

Series : P

Unit Height Shipping Oracle ERP : 15

Unit Length Shipping Oracle ERP : 27

Unit Width Shipping Oracle ERP : 17

Dimension A mm : 210

Dimension B mm : 308

Dimension C mm : 163

Dimension D mm : 320

Dimension E mm : 195

Dimension H mm : 671

Dimension J mm : 25

Weight Kgs : 27,7

Hydraulic Pump Dimension L mm : 270

Hydraulic Pump Dimension M mm : 175

Hydraulic Pump Dimension N mm : 650

Hydraulic Pump Dimension P mm : 92

Hydraulic Pump Dimension Q mm : 89

Hydraulic Pump Dimension R mm : 68

Hydraulic Pump Dimension S mm : 80

Hydraulic Pump Maximum Flow Rate Ranges at Rated Pressure In 3 min : 0 - 20

Hydraulic Pump Maximum Flowat Rated Pressure : 4,75 cm3/stroke

Hydraulic Pump Maximum Handle Effort kg : 49

Hydraulic Pump Maximum Operating Pressure Ranges Bar : 700

Hydraulic Pump Maximum Operating Pressure Ranges Psi : 10,000

Hydraulic Pump Oil Displacement Per Stroke 1st Stage cm3 : 126,20

Hydraulic Pump Oil Displacement Per Stroke 2nd Stage cm3 : 4,75

Hydraulic Pump Piston Stroke mm : 38,1

Hydraulic Pump Pressure Rating 1st Stage Psi : 200

Hydraulic Pump Pressure Rating 1st Stage bar : 14

Hydraulic Pump Pressure Rating 2nd Stage bar : 700

Hydraulic Pump Pressure Rating 2nd Stage Psi : 10,000

Hydraulic Pump Power Source : Manual

Hydraulic Pump Reservoir Capacity cm3 : 7423

Hydraulic Pump Usable Oil Capacity cm3 : 7423

Hydraulic Pump Valve Operation : Manual

Hydraulic Pump Maximum Flow At Rated Pressure Liter : 0.00475

Hydraulic Pump Maximum Flow At Rated Pressure Metric : 4,75 cm3/stroke

PLG: default Price Group List Price : 1

Description

  • Extensions – Stackable, with large alloy steel locating studs to resist effects of side-loading
  • PLE11 and PLE14 extensions and PLB12 extension base adapter are to be used with the “short” model PL20014ASA only

Additional information

Weight 27.364 kg

Reviews

There are no reviews yet.

Be the first to review “P464”
