P462

SKU: P462 Categories: , , Brand:
Login to purchase
Enquire for this product

Maximum Operating Pressure psi : 10,000

Maximum Operating Pressure bar : 700

Series : P

Unit Height Shipping Oracle ERP : 15

Unit Length Shipping Oracle ERP : 27

Unit Width Shipping Oracle ERP : 17

Dimension A mm : 210

Dimension B mm : 308

Dimension C mm : 163

Dimension D mm : 320

Dimension E mm : 195

Dimension H mm : 671

Dimension J mm : 25

Weight Kgs : 27,7

Hydraulic Pump Cylinder Compatability : Single-acting

Hydraulic Pump Dimension L mm : 270

Hydraulic Pump Dimension M mm : 175

Hydraulic Pump Dimension N mm : 650

Hydraulic Pump Dimension P mm : 92

Hydraulic Pump Dimension S mm : 80

Hydraulic Pump Maximum Flow Rate Ranges at Rated Pressure In 3 min : 0 - 20

Hydraulic Pump Maximum Flowat Rated Pressure : 4,75 cm3/stroke

Hydraulic Pump Maximum Handle Effort kg : 49

Hydraulic Pump Maximum Operating Pressure Ranges Bar : 700

Hydraulic Pump Maximum Operating Pressure Ranges Psi : 10,000

Hydraulic Pump Oil Displacement Per Stroke 1st Stage cm3 : 126,20

Hydraulic Pump Oil Displacement Per Stroke 2nd Stage cm3 : 4,75

Hydraulic Pump Piston Stroke mm : 38,1

Hydraulic Pump Pressure Rating 1st Stage Psi : 200

Hydraulic Pump Pressure Rating 1st Stage bar : 14

Hydraulic Pump Pressure Rating 2nd Stage bar : 700

Hydraulic Pump Pressure Rating 2nd Stage Psi : 10,000

Hydraulic Pump Power Source : Manual

Hydraulic Pump Reservoir Capacity cm3 : 7423

Hydraulic Pump Usable Oil Capacity cm3 : 7423

Hydraulic Pump Valve Operation : Manual

Hydraulic Pump Maximum Flow At Rated Pressure Liter : 0.00475

Hydraulic Pump Maximum Flow At Rated Pressure Metric : 4,75 cm3/stroke

PLG: default Price Group List Price : 1

Description

  • Flat Load Cap – Non-tilt load cap has lower profile for tight lifting space

Additional information

Weight 27.411 kg
