P392

Description

• The Pow’R-LOCK™ Lift System provides continuous positive locking of the load through all stages of lifting and lowering. No operator intervention is required to activate or deactivate the automatic locking system
• Provides continuous locking protection during lift, lower and hold functions
• Patent-pending control technology synchronizes cylinder and lock nut for smooth and efficient lifting and lowering
• Unique double-acting cylinder offers a low collapsed height to accomodate more lifting applications
• Simple 2-button pendant allows operation of raise and lower functions from up to 6,1 metres away
• All exposed load-bearing steel cylinder components utilize a nitrocarburizing treatment to reduce wear and resist corrosion
• Ergonomic handle has six positions for comfortable handling and folds when not in use
• Meets ANSI/ASME B30.1-2015, AS/NZS-2538, AS/NZS-2693 certification criteria
• All POW’R-LOCK™ Lift System models feature a Tilt Load Cap to reduce side-loading
• Enerpac declares that this product has been tested and conforms to applicable standards and is approved to carry the CE mark. An EU Declaration of Conformity is enclosed separately.
• Minimum dynamic air pressure of 3,8-4,1 bar, 6,2-6,9 bar required to achieve 1779 kN capacity.
• Safety First – When lifting large, heavy vehicles certain precautions must be followed. Follow your published safety directions for lifting and cribbing your loads. The Pow’R-LOCK™ Lift System provides load/lock protection, but you must follow the safety directions for load cribbing operations.
