Maximum Operating Pressure psi : 10,000
Maximum Operating Pressure bar : 700
Series : P
Unit Height Shipping Oracle ERP : 8
Unit Length Shipping Oracle ERP : 6
Unit Width Shipping Oracle ERP : 23
Dimension A mm : 344
Dimension B mm : 533
Dimension C mm : 36
Dimension D mm : 99
Dimension E mm : 33
Dimension H mm : 522
Dimension J mm : 30
Weight Kgs : 4,1
Hydraulic Pump Cylinder Compatability : Single-acting
Hydraulic Pump Dimension L mm : 177
Hydraulic Pump Dimension M mm : 16
Hydraulic Pump Dimension N mm : 120
Hydraulic Pump Maximum Flow Rate Ranges at Rated Pressure In 3 min : 0 - 20
Hydraulic Pump Maximum Flowat Rated Pressure : 2,47 cm3/stroke
Hydraulic Pump Maximum Handle Effort kg : 38,6
Hydraulic Pump Maximum Operating Pressure Ranges Bar : 700
Hydraulic Pump Maximum Operating Pressure Ranges Psi : 10,000
Hydraulic Pump Oil Displacement Per Stroke 1st Stage cm3 : 2,47
Hydraulic Pump Oil Displacement Per Stroke 2nd Stage cm3 : -
Hydraulic Pump Piston Stroke mm : 25,4
Hydraulic Pump Pressure Rating 1st Stage Psi : 10,000
Hydraulic Pump Pressure Rating 1st Stage bar : 700
Hydraulic Pump Pressure Rating 2nd Stage bar : -
Hydraulic Pump Pressure Rating 2nd Stage Psi : -
Hydraulic Pump Power Source : Manual
Hydraulic Pump Reservoir Capacity cm3 : 901
Hydraulic Pump Usable Oil Capacity cm3 : 901
Hydraulic Pump Valve Operation : Manual
Hydraulic Pump Maximum Flow At Rated Pressure Liter : 0.00247
Hydraulic Pump Maximum Flow At Rated Pressure Metric : 2,47 cm3/stroke
PLG: default Price Group List Price : 1
