NSH5065
NSH5065 - Image 2

NSH5065

SKU: NSH5065 Categories: , , Brand:
Login to purchase
Enquire for this product

Maximum Operating Pressure psi : 10,000

Maximum Operating Pressure bar : 700

Series : NSH

Capacity KN : 360

Dimension A mm : 377

Dimension B mm : 322

Dimension C mm : 210

Dimension D mm : 185

Weight Kgs : 10,9

Cutter Cutter Head Return Type : Single-Acting, Spring Return

Cutter Maximum Allowable Hardness to Split : ASTM A194 Gr 2H

Cutter Bolt Range mm : M33 - M42

Cutter Cutting Tip Service Kit Model Number : NSH5065CTK

Cutter Dimension H Max mm : 45

Cutter Dimension N Min mm : 23,0

Cutter Dimension S Max mm : 49,5

Cutter Dimension T mm : 52,0

Cutter Dimension W Min mm : 108,0

Cutter Hexagon Nut Range mm : 50 - 65

Cutter Oil Capacity C m3 : 230

PLG: default Price Group List Price : 1
