NSH2432
NSH2432 - Image 2
NSH2432 - Image 3

NSH2432

SKU: NSH2432 Categories: , , Brand:
Login to purchase
Enquire for this product

Maximum Operating Pressure psi : 10,000

Maximum Operating Pressure bar : 700

Series : NSH

Capacity KN : 150

Dimension A mm : 265

Dimension B mm : 220

Dimension C mm : 152

Dimension D mm : 81

Weight Kgs : 4,0

Cutter Cutter Head Return Type : Single-Acting, Spring Return

Cutter Maximum Allowable Hardness to Split : ASTM A194 Gr 2H

Cutter Bolt Range mm : M16 - M22

Cutter Cutting Tip Service Kit Model Number : NSH2432CTK

Cutter Dimension H Max mm : 25

Cutter Dimension N Min mm : 9,0

Cutter Dimension S Max mm : 26,5

Cutter Dimension T mm : 32,0

Cutter Dimension W Min mm : 57,5

Cutter Hexagon Nut Range mm : 24 - 32

Cutter Oil Capacity C m3 : 46

PLG: default Price Group List Price : 1

Description

  • Pumps oil in both forward and reverse handle movement improving overall efficiency, ideal when mounting space is restricted
  • External load-release valve
  • Internal pressure-relief valve for overload protection
