NC1019

NC1019

SKU: NC1019 Categories: , , Brand:
Login to purchase
Enquire for this product

Maximum Operating Pressure psi : 10,000

Maximum Operating Pressure bar : 700

Series : NC

Capacity KN : 49

Dimension A mm : 40

Dimension B mm : 170

Dimension C mm : 7

Dimension D mm : 19

Dimension F mm : 28

Dimension H mm : 48

Dimension J mm : 21

Weight Kgs : 1,2

Cutter Cutter Head Return Type : Single-Acting, Spring Return

Cutter Maximum Allowable Hardness to Split : HRC 44

Cutter Replacement Chisel Model Number : NCB1019

Cutter Bolt Range mm : M6 - M12

Cutter Hexagon Nut Range mm : 19-Oct

Cutter Oil Capacity C m3 : 15

Cutter Replacement Chisel Model Number Moving : NCB1019

PLG: default Price Group List Price : 1

Description

  • Quick and easy cutting tip replacement
  • Drop-tested revolving anchor point and safety lanyard
  • Revolving composite handle for vibration and shock isolation
  • Nut Splitters include set of hexagon keys and following spare parts:
    – cutting tip
    – tip retention screw
    – spare alignment screw
  • Standard Safety Lanyard with each nut splitter. Includes steel cable with carabiners.
  • CR400 female half coupler is standard
  • Maximum allowable hardness to split is ASTM A194 Gr 2H. Not to be used on square nuts or stainless steel.

Reviews

There are no reviews yet.

Be the first to review “NC1019”

Your email address will not be published. Required fields are marked *
