Maximum Operating Pressure psi : 10,000
Maximum Operating Pressure bar : 700
Series : MP
Unit Height Shipping Oracle ERP : 8
Unit Length Shipping Oracle ERP : 28
Unit Width Shipping Oracle ERP : 8
Weight Kgs : 6,6
Hydraulic Pump Cylinder Compatability : Single-acting
Hydraulic Pump Maximum Flow Rate Ranges at Rated Pressure In 3 min : 0 - 20
Hydraulic Pump Maximum Flowat Rated Pressure : 3,1 cm3/stroke
Hydraulic Pump Maximum Handle Effort kg : 45
Hydraulic Pump Maximum Operating Pressure Ranges Bar : 700
Hydraulic Pump Maximum Operating Pressure Ranges Psi : 10,000
Hydraulic Pump Oil Displacement Per Stroke 1st Stage cm3 : 52,6
Hydraulic Pump Oil Displacement Per Stroke 2nd Stage cm3 : 3,1
Hydraulic Pump Piston Stroke mm : 26,5
Hydraulic Pump Pressure Rating 1st Stage Psi : 500
Hydraulic Pump Pressure Rating 1st Stage bar : 35
Hydraulic Pump Pressure Rating 2nd Stage bar : 700
Hydraulic Pump Pressure Rating 2nd Stage Psi : 10,000
Hydraulic Pump Power Source : Manual
Hydraulic Pump Valve Operation : Manual
Hydraulic Pump Maximum Flow At Rated Pressure Liter : 0
Hydraulic Pump Maximum Flow At Rated Pressure Metric : 3,1 cm3/stroke
PLG: default Price Group List Price : 1
