Maximum Operating Pressure psi : 10,000
Maximum Operating Pressure bar : 700
Series : LW
Stroke mm : 21
Unit Height Shipping Oracle ERP : 6
Unit Length Shipping Oracle ERP : 14
Unit Width Shipping Oracle ERP : 7
Capacity KN : 157
Weight Kgs : 7,0
Spreader Maximum Lift Per Stage : 21
Spreader Maximum Lifting Height Using Stepped Block : 2.72
Spreader maximum Lifting Force KN : 157
Spreader maximum Lifting Height Mm : 51,5
Spreader maximum Lifting Height Using Stepped Block Mm : 69,0
Spreader maximum Spread Mm : 21
Spreader minimum Clearance Gap Mm : 10
Spreader oil Capacity Cm3 : 78
Spreader spreader Power Source : Hydraulic
PLG: default Price Group List Price : 1
