LPL1002

LPL1002

SKU: LPL1002 Categories: , , Brand:
Login to purchase
Enquire for this product

Maximum Operating Pressure psi : 10,150

Maximum Operating Pressure bar : 700

Series : LPL

Stroke mm : 50

Weight Kgs : 26

Hydraulic Cylinders Base to Advance Port H mm : 21

Hydraulic Cylinders Collapsed Height A mm : 137

Hydraulic Cylinders Cylinder Bore Diameter E mm : 135

Hydraulic Cylinders Cylinder Effective Area Advance cm2 : 143,1

Hydraulic Cylinders Extended Height B mm : 187

Hydraulic Cylinders Lock Nut Height S mm : 31

Hydraulic Cylinders Maximum Cylinder Capacity Advance kn : 1027

Hydraulic Cylinders Maximum Operating Pressure Ranges psi : 10,000

Hydraulic Cylinders Outside Diameter D mm : 175

Hydraulic Cylinders Saddle Diameter J1 mm : 126

Hydraulic Cylinders Saddle Protrusion from Plunger K1 mm : 8

Hydraulic Cylinders Sideload Resistance of Maximum Capacity Percentage : 10%

Hydraulic Cylinders Collapsed Height A Ranges Mm : 128 - 254

Hydraulic Cylinders Return Type : Single-Acting, Load Return

Hydraulic Cylinders Saddle Diameter J mm : 126

Hydraulic Cylinders Saddle Protrusion From Plunger K mm : 8

Hydraulic Cylinders Stroke Ranges mm : 48 - 94

PLG: default Price Group List Price : 1

Description

  • Enerpac Maintenance sets are a complete assortment of accessories matched to hydraulic powered tools. Using these sets allows you to quickly configure a unique tool to meet your most difficult jobs.Built around the Enerpac lightweight hand pump, hose and cylinder, these sets enable you to push, pull, lift, press, straighten, spread and clamp.
  • All sets include a pump, hose, cylinder, and gauge
  • Lock-on or threaded connectors
  • Complete set for almost every maintenance application
  • When cylinders are used with maintenance set attach ments or components, the maximum system pressure must be limited to half the rated pressure (350 bar).
  • If no attachments are being used, capacity is double these values. Maximum operating pressure is then 700 bar
  • Only use attachments provided with set. Non-Enerpac attachments and longer extension tubes will reduce column strength, potentially creating unsafe conditions

Additional information

Weight 32 kg
