LA2504TX-QR
LA2504TX-QR - Image 2

LA2504TX-QR

SKU: LA2504TX-QR Categories: , , Brand:
Login to purchase
Enquire for this product

Maximum Operating Pressure psi : 10,000

Maximum Operating Pressure bar : 700

Series : LAT

Weight Kgs : 18,0

Hydraulic Pump Air Consumption Scfm : 65

Hydraulic Pump Air Pressure Range Psi : 65-100

Hydraulic Pump Air Pressure Range bar : 4,5-6,9

Hydraulic Pump Dimension Lx Wx H mm : 435x250x375

Hydraulic Pump For Use With Torque Wrenches : For use with all Enerpac torque wrenches

Hydraulic Pump Maximum Flow Rate Ranges at Rated Pressure In 3 min : 25 - 214

Hydraulic Pump Maximum Flow Rate Ranges at Rated Pressure L min : 0,4 - 3,5

Hydraulic Pump Maximum Operating Pressure Ranges Bar : 700

Hydraulic Pump Maximum Operating Pressure Ranges Psi : 10,000

Hydraulic Pump Oil Flow Per Outlet At 10000 Psi In 3 Min : 25

Hydraulic Pump Oil Flow Per Outlet At 700 Bar L Min : 0,4

Hydraulic Pump Output Flow Rate 10000 Psi In 3min : 25

Hydraulic Pump Output Flow Rate 100 psi In 3min : 214

Hydraulic Pump Output Flow Rate 350 bar L min : 0,6

Hydraulic Pump Output Flow Rate 5000 Psi In 3 min : 34

Hydraulic Pump Output Flow Rate 700 bar L min : 0,4

Hydraulic Pump Output Flow Rate At 0 psi In 3 min : 214

Hydraulic Pump Output Flow Rate At Maximum Pressure In 3 min : 25

Hydraulic Pump Pressure Rating bar : 700

Hydraulic Pump Pressure Rating psi : 10,000

Hydraulic Pump Control : Pendant

Hydraulic Pump Power Source : Air

Hydraulic Pump Relief Valve Adjustment Range Psi : 2,000 - 10,000

Hydraulic Pump Relief Valve Adjustment Range bar : 138 - 700

Hydraulic Pump Reservoir Capacity Litres : 3,0

Hydraulic Pump Reservoir Capacity cm3 : 3,000

Hydraulic Pump Reservoir Capacity gal : 1

Hydraulic Pump Sound Leveld Ba : 87 - 90

Hydraulic Pump Usable Oil capacity Gal : 1

Hydraulic Pump Usable Oil Capacity Litres : 1,9

Hydraulic Pump Valve Type : 4-vie, 2-posizioni

Hydraulic Pump Air Consumption L min : 1,389

Hydraulic Pump Maximum Flow At Rated Pressure Liter : 0

Hydraulic Pump Packaging Dimensions mm : 584 x 562 x 460

PLG: default Price Group List Price : 1

Description

  • LGH-Series Pullers provide the same safety and ease of use as their mechanical counterparts, with the pulling force applied by a standard 700 bar hydraulic cylinder.
  • Quickly and easily mount on a wide range of applications
  • Turning the puller handle locks the jaws onto the application, allowing the desired object to be pulled free when the spindle is turned.
  • Hydraulically applied pulling force increases pulling capacity, reducing operator fatigue
  • Lock-on jaws offer a secure grip for safe and easy operation
  • Synchronous jaw movement enables entire pulling job to be performed by a single operator
  • LGH-Series Pullers MUST be used with a point protector if the shaft end does not contain a drilled center hole. One point protector is included with every puller.
  • Always wear safety goggles and gloves while using pullers.

Additional information

Weight 22 kg
