Maximum Operating Pressure bar : 700
Series : IP
Dimension B mm : 530
Dimension C mm : 1371
Dimension D mm : 263
Dimension E mm : 745
Dimension F mm : 1085
Dimension G mm : 127
Dimension H mm : 222
Dimension J mm : 914
Dimension K mm : 212
Weight Kgs : 523
Hydraulic Press Compatible Cylinders : 50 ton RC-Cylinder
Hydraulic Press Cylinder Type : Single-Acting
Hydraulic Press Power Source Type : Electric
Hydraulic Press Power Source Valve : Electric
Hydraulic Press Cylinder Stroke mm : 330
Hydraulic Press Dimension L mm : 394
Hydraulic Press Dimension M mm : 790
Hydraulic Press Dimension N mm : 1930
Hydraulic Press Maximum Bed Width mm : 736
Hydraulic Press maximum Vertical Daylight mm : 1406
Hydraulic Press Press Capacity KN : 498
Hydraulic Press Rapid Advance Speed mm sec : 20,8
Hydraulic Press Vertical Daylight Maximum A mm : 1406
Hydraulic Press Vertical Daylight Minimum A mm : 195
