EWCH180

EWCH180

SKU: EWCH180 Categories: , , Brand:
Login to purchase
Enquire for this product

Maximum Operating Pressure psi : 10,000

Maximum Operating Pressure bar : 700

Series : EWCH

Compatible Products : ZE6410XM-S,ZE6410XG-S,ZE6410XW-S,ZE6410XK-S,ZE6410XJ-S,CH720EC,CPLRKP

Dimension A mm : 1364

Dimension B mm : 211

Dimension C mm : 401

Dimension D mm : 551

Weight Kgs : 149,5

Cutter Maximum Allowable Hardness to Split : HRc 43

Cutter Maximum Material Diameter mm : 180

Cutter Maximum Material Tensile Strength da N mm2 : 65

Cutter Cutter Pump Power Source : Electric Pump

Cutter Cutter Power Source : Electric

Cutter Maximum Material Tensile Strength Psi : 94,275

PLG: default Price Group List Price : 1

Description

  • Dual scale reading calibrated in bar and psi
  • All pressure sensing parts sealed and dampened by glycerine for long life
  • Includes safety blow-out disk and pressure equalizing membrane
  • Copper alloy, coiled safety Bourdon tube for 70 bar and higher
  • ± 1.5% accuracy of full scale
  • Gauge snubbers or needle valves recommended for high cycle applications.

Additional information

Weight 150 kg
