Maximum Operating Pressure psi : 10,000
Maximum Operating Pressure bar : 700
Series : EVOP
Dimension A mm : 1368
Dimension B mm : 1250
Dimension C mm : 805
Weight Kgs : 490
Hydraulic Pump Accuracy Over Full Stroke : 1 mm
Hydraulic Pump Maximum Flow Rate Ranges at Rated Pressure In 3 min : > 200
Hydraulic Pump Maximum Flow Rate Ranges at Rated Pressure L min : > 3,27
Hydraulic Pump Maximum Operating Pressure Ranges Bar : 700
Hydraulic Pump Maximum Operating Pressure Ranges Psi : 10,000
Hydraulic Pump Motor Hertz : 50/60 Hz
Hydraulic Pump Motor Phases : 3 Ph
Hydraulic Pump Motor Size hp : 10
Hydraulic Pump Motor Voltage : 460-480 V
Hydraulic Pump Number Of Lift Points : 1
Hydraulic Pump Number Of Outlets : 1
Hydraulic Pump Output Flow Rate 10000 Psi In 3min : 244
Hydraulic Pump Output Flow Rate 100 psi In 3min : 793
Hydraulic Pump Reservoir Capacity cm3 : 150000
Hydraulic Pump Reservoir Capacity gal : 40
Hydraulic Pump Reservoir Size Ranges Gallons : > 10
Hydraulic Pump Usable Oil Capacity Litres : 150
Hydraulic Pump Variable Output Flow High Pressure Greater Than 125 bar l Min : 1,2-4,0
Hydraulic Pump Variable Output Flow High Pressure Greater Than 1800 Psi In 3 Min : 73-244
Hydraulic Pump Variable Output Flow Low Pressure Less Than 125 bar l Min : 3,9-13,0
Hydraulic Pump Variable Output Flow Low Pressure Less Than 1800 Psi In 3 Min : 238-793
Hydraulic Pump Maximum Flow At Rated Pressure Liter : 4,0
PLG: default Price Group List Price : 1
