CULP50

CULP50

SKU: CULP50 Categories: , , Brand:
Login to purchase
Enquire for this product

Maximum Operating Pressure psi : 10,150

Maximum Operating Pressure bar : 700

Series : CULP

Stroke mm : 6

Weight Kgs : 5,4

Hydraulic Cylinders Collapsed Height A mm : 44.5

Hydraulic Cylinders Cylinder Bore Diameter E mm : 100

Hydraulic Cylinders Cylinder Effective Area Advance cm2 : 78,5

Hydraulic Cylinders Maximum Cylinder Capacity Advance kn : 550

Hydraulic Cylinders Maximum Operating Pressure Ranges psi : 10,000

Hydraulic Cylinders Outside Diameter D mm : 140

Hydraulic Cylinders Collapsed Height A Ranges Mm : 0 - 127

Hydraulic Cylinders Return Type : Single-Acting, Load Return

Hydraulic Cylinders Stroke Ranges mm : 0 - 23

PLG: default Price Group List Price : 1

Additional information

Weight 4.7 kg
