Maximum Operating Pressure psi : 10,000
Maximum Operating Pressure bar : 700
Series : BRP
Stroke mm : 150
Unit Height Shipping Oracle ERP : 8
Unit Length Shipping Oracle ERP : 33
Unit Width Shipping Oracle ERP : 8
Weight Kgs : 15,3
Hydraulic Cylinders Collapsed Height A mm : 601
Hydraulic Cylinders Cylinder Effective Area Retract cm2 : 15,8
Hydraulic Cylinders Extended Height B mm : 751
Hydraulic Cylinders Link Width N mm : 35
Hydraulic Cylinders Maximum Cylinder Capacity Retract kn : 105
Hydraulic Cylinders Maximum Operating Pressure Ranges psi : 10,000
Hydraulic Cylinders Outside Diameter D mm : 85
Hydraulic Cylinders Slot To Link End T mm : 32
Hydraulic Cylinders Collapsed Height A Ranges Mm : 509 - 635
Hydraulic Cylinders Link Height J mm : 105
Hydraulic Cylinders Link Opening L mm : 87
Hydraulic Cylinders Link Thickness M mm : 30
Hydraulic Cylinders Oil Capacity Retract Cm3 : 238
Hydraulic Cylinders Return Type : Single-Acting, Spring Return
Hydraulic Cylinders Stroke Ranges mm : 120 - 174
