Maximum Operating Pressure psi : 10,000
Maximum Operating Pressure bar : 700
Series : BLS
Stroke mm : 151
Dimension A mm : 510
Dimension B mm : 661
Dimension C mm : 387
Dimension D mm : 248
Dimension F mm : 133
Dimension H mm : 102
Dimension J mm : 130
Dimension K mm : 550
Weight Kgs : 373
Hydraulic Cylinders Cylinder Effective Area Advance cm2 : 285,6
Hydraulic Cylinders Cylinder Effective Area Retract cm2 : 145,6
Hydraulic Cylinders Dimension M mm : 140
Hydraulic Cylinders Dimension N mm : 135
Hydraulic Cylinders Maximum Cylinder Capacity Advance kn : 1995
Hydraulic Cylinders Maximum Cylinder Capacity Retract kn : 1017
Hydraulic Cylinders Maximum Operating Pressure Ranges psi : 10,000
Hydraulic Cylinders Dimension J1 mm : 270
Hydraulic Cylinders Dimension L mm : 575
Hydraulic Cylinders Oil Capacity Advance Cm3 : 4332
Hydraulic Cylinders Oil Capacity Retract Cm3 : 2209
Hydraulic Cylinders Return Type : Double-Acting, Hydraulic Return
Hydraulic Cylinders Stroke Ranges mm : 120 - 174
PLG: default Price Group List Price : 1
