Maximum Operating Pressure psi : 10,000
Maximum Operating Pressure bar : 700
Series : BLS
Stroke mm : 151
Dimension A mm : 472
Dimension B mm : 624
Dimension C mm : 370
Dimension D mm : 203
Dimension F mm : 114
Dimension H mm : 94
Dimension J mm : 130
Dimension K mm : 475
Weight Kgs : 322
Hydraulic Cylinders Cylinder Effective Area Advance cm2 : 198,1
Hydraulic Cylinders Cylinder Effective Area Retract cm2 : 95,4
Hydraulic Cylinders Dimension M mm : 140
Hydraulic Cylinders Dimension N mm : 322
Hydraulic Cylinders Maximum Cylinder Capacity Advance kn : 1386
Hydraulic Cylinders Maximum Cylinder Capacity Retract kn : 668
Hydraulic Cylinders Maximum Operating Pressure Ranges psi : 10,000
Hydraulic Cylinders Dimension J1 mm : 230
Hydraulic Cylinders Dimension L mm : 500
Hydraulic Cylinders Oil Capacity Advance Cm3 : 3090
Hydraulic Cylinders Oil Capacity Retract Cm3 : 1488
Hydraulic Cylinders Return Type : Double-Acting, Hydraulic Return
Hydraulic Cylinders Stroke Ranges mm : 120 - 174
