Maximum Operating Pressure psi : 10,000
Maximum Operating Pressure bar : 700
Series : A
Unit Height Shipping Oracle ERP : 16
Unit Length Shipping Oracle ERP : 26
Unit Width Shipping Oracle ERP : 8
Capacity KN : 267
Dimension A mm : 563
Dimension B mm : 356
Dimension C mm : 254
Dimension D mm : 188
Dimension E mm : 178
Dimension G mm : 63
Dimension H mm : 140
Dimension J mm : 28
Dimension K mm : 168
Height Dimension mm : 557.28
Length Dimension mm : 353
Weight Kgs : 100
Width Dimension mm : 177.8
Hydraulic Press Compatible Cylinders : RC308
Hydraulic Press Cylinder Type : Single-Acting
Hydraulic Press Maximum Operating Pressure : 10,000
Hydraulic Press Dimension L mm : 203
Hydraulic Press Dimension M mm : 67
Hydraulic Press Dimension N mm : 98
Hydraulic Press Dimension O mm : 276
Hydraulic Press Maximum Bed Width mm : 178
Hydraulic Press maximum Vertical Daylight mm : 260
Hydraulic Press Press Capacity KN : 267
PLG: default Price Group List Price : 1
