Maximum Operating Pressure psi : 10,000
Maximum Operating Pressure bar : 700
Series : A
Unit Height Shipping Oracle ERP : 14.8
Unit Length Shipping Oracle ERP : 17.7
Unit Width Shipping Oracle ERP : 9.5
Capacity KN : 89
Dimension A mm : 414
Dimension B mm : 281
Dimension C mm : 230
Dimension D mm : 184
Dimension E mm : 151
Dimension G mm : 63
Dimension H mm : 122
Dimension J mm : 19
Dimension K mm : 95
Height Dimension mm : 414
Length Dimension mm : 291
Weight Kgs : 28
Width Dimension mm : 135
Hydraulic Press Compatible Cylinders : RC101,RC102,RC104,RC106,RC108,RC1010,RC1012,RC1014
Hydraulic Press Cylinder Type : Single-Acting
Hydraulic Press Maximum Operating Pressure : 10,000
Hydraulic Press Dimension L mm : 175
Hydraulic Press Dimension M mm : 65
Hydraulic Press Dimension N mm : 54
Hydraulic Press Dimension O mm : 219
Hydraulic Press Maximum Bed Width mm : 135
Hydraulic Press maximum Vertical Daylight mm : 227
Hydraulic Press Press Capacity KN : 89
PLG: default Price Group List Price : 1
