11400

SKU: 11400 Categories: , , Brand:
Login to purchase
Enquire for this product

Maximum Operating Pressure psi : 40,000

Maximum Operating Pressure bar : 2800

Series : 11

Unit Height Shipping Oracle ERP : 10

Unit Length Shipping Oracle ERP : 15

Unit Width Shipping Oracle ERP : 9

Dimension A mm : 240

Dimension B mm : 266

Dimension C mm : 151

Dimension D mm : 177

Dimension E mm : 45

Dimension H mm : 635

Dimension J mm : 162

Weight Kgs : 10,0

Hydraulic Pump Cylinder Compatability : Single-acting

Hydraulic Pump Dimension L mm : 114

Hydraulic Pump Dimension M mm : 237

Hydraulic Pump Dimension N mm : 314

Hydraulic Pump Dimension S mm : 7

Hydraulic Pump Dimension T mm : 9

Hydraulic Pump Maximum Flow Rate Ranges at Rated Pressure In 3 min : 0 - 20

Hydraulic Pump Maximum Flowat Rated Pressure : 0,62 cm3/stroke

Hydraulic Pump Maximum Handle Effort kg : 54,4

Hydraulic Pump Maximum Operating Pressure Ranges Bar : > 800

Hydraulic Pump Maximum Operating Pressure Ranges Psi : > 11,600

Hydraulic Pump Oil Displacement Per Stroke cm3 : 0,62

Hydraulic Pump Piston Stroke mm : 19,8

Hydraulic Pump Pressure Rating 2nd Stage bar : 2,800

Hydraulic Pump Pressure Rating 2nd Stage Psi : 40,000

Hydraulic Pump Power Source : Manual

Hydraulic Pump Reservoir Capacity cm3 : 737

Hydraulic Pump Usable Oil Capacity cm3 : 737

Hydraulic Pump Valve Operation : Manual

Hydraulic Pump Maximum Flow At Rated Pressure Liter : 0.00062

Hydraulic Pump Maximum Flow At Rated Pressure Metric : 0,62 cm3/stroke

PLG: default Price Group List Price : 1

Additional information

Weight 6.903 kg
